Wall Mount Coolers 300 W - 230 Vac

 Introduction

• Standard seal applied to cabinet-facing surface of the coolers of BASE and TOP version

• Inbuilt condensation sink on BASE and TOP versions

• Standard air filter on BASE and TOP versions.

• Textured RAL 7035 standard colour. Other colours are available upon request.

• The connection is performed by means of PLUG-IN terminal boards:

◊ BASE - 1 PLUG-IN power supply. Visual alarm of minimum/maximum temperature.

◊ TOP - 2 PLUG-IN power supply connectors. Alarm control by means of a terminal board. Remote ON/OFF. RS485 serial interface for remote control.

• Versions with non-standard supply voltage are available upon request.




Optional:

Non-standard colour = R9KLMxxxxxLB/T (Required RAL code is to be specified)

AISI 304 case = RIKLMxxxxxLB/T

AISI 316 case = R6KLMxxxxxLB/T


Air flow


Dimensions and mounting cut-outs (mm)








DKC Ramklima Catalogue-Cooling Systems for Electrical Enclosures
