ST Electrical Housing Solid Door
CHARACTERISTICS AND COMPOSITION Sheet steel housing without cable entry, with external, welded, anti-rotation
and anti-extraction M6 stud bolt (H = 15 mm) in copper-coated steel.
Reversible door in sheet steel with ø 3 mm double fin locking system
(box and insert in zinc alloy, tab in stainless steel).
Mounting plate made from sendzimir sheet steel.
Set of screws for grounding and assembly.
PAINTING
E DUP - cathodic electrophoresis paint with epoxy resin and finish with
thermosetting epoxy-polyester powders for ETA standard electrostatic cycle.
Colour: RAL7035 textured.
PROTECTION RATING
IP66 compliant with IEC EN62208 and EN60529.
NEMA4 compliant with UL508A; UL50.
Protection rating ensured by the two-component polyurethane foam gasket.
Impact resistance rating IK10 compliant with IEC EN62208 and EN62262.
PERFORMANCE
Ex II 2G - Ex e IIC Gb - Ex II 2GD - Ex tb IIIC Db.  SOLUTION CREATED WITH ST CONSTRUCTION CONCEPT
 |
