2000 W

 Introduction
Wall mounted indoor coolers

• Injected gasket on cabinet side as standard for BASE and TOP version
• Inbuilt condensate evaporator on TOP versions.
• Standard air filter on BASE and TOP versions.
• Textured RAL 7035 standard color. Other colors are available upon request.
• The connection is performed by means of PLUG-IN terminal boards:
  - BASE - 1 PLUG-IN power supply. Visual alarm of minimum/maximum
    temperature. Modifiable intervention set.
  - TOP - 2 PLUG-IN power supply connectors. Over temperature alarm
    control by means of a terminal board.
    Remote ON/OFF (door contact switch). RS485 serial interface for
    remote control (to be requested in order phase).
• Special voltage upon request.
• All two-phase and three-phase versions can be supplied with different voltages,
  by changing the internal wiring (follow diagrams). Take a look at the diagrams
  for the available voltages.
• UL versions: not supplied configuration TOP grille / filter.
• All UL versions with supply voltages of 460 Vac can be supplied with voltage
  480 Vac. Request in order phase.

Temperature regulating range (factory set) from /to +30°C / +40°C
Noise level 67 dB (A)
Coolant type R134a
Operating cycle type 100%


                                                                                                        Optional
                                                                                                        SPECIAL COLOR = R9KLM...
                                                                                                        AISI INOX 304 FRONT COVER = RIKLM...
                                                                                                        AISI INOX 316 FRONT COVER = RI6KLM...
