Wall mount indoor coolers
• Injected gasket on cabinet side as standard for BASE and TOP version
• Inbuilt condensate evaporator on TOP versions.
• Standard air filter on BASE and TOP versions.
• Textured RAL 7035 standard color. Other colors are available upon request.
• The connection is performed by means of PLUG-IN terminal boards:
- BASE - 1 PLUG-IN power supply. Visual alarm of minimum/maximum
temperature. Modifiable intervention set.
- TOP - 2 PLUG-IN power supply connectors. Over temperature alarm
control by means of a terminal board.
Remote ON/OFF (door contact switch). RS485 serial interface for
remote control (to be requested in order phase).
• Special voltage upon request.
• All two-phase and three-phase versions can be supplied with different voltages,
by changing the internal wiring (follow diagrams). Check the diagrams for available voltages.
• UL versions: not supplied configuration TOP grille / filter.
• All UL versions with supply voltages of
460 Vac can be supplied with voltage
480 Vac. Request in order phase.
Temperature regulating range (factory set) from /to +30°C / +40°C
Noise level 67 dB (A)
Coolant type R134a
Operating cycle type 100%
 Optional
SPECIAL COLOR = R9KLM...
AISI INOX 304 FRONT COVER = RIKLM...
AISI INOX 316 FRONT COVER = RI6KLM...
  |
