With filter R5GV4

 Introduction
With filter R5GV4

• Material:PC/ABS UV resistant
• Mounting: by means of elastic clips or 4 self-tapping screws
• Filtering media: thermo-linked
  progressive structure synthetic fibre
• Mounting range: thickness from 1 to 2,5 mm.
• Earthing connection: by M4 screws on the fan case

Storing temperature from -40°C to +70°C
Lifespan L10 a 20°C 50.000 h
Motor protection Impedance
Application class Class I
Filtering CLASS G3 as per EN 779
Separation grade 85% - DIN 24185
Dust retention capacity 600 g/m2
Weight 1,5 kg

Note
Filter media washable up to 10 times
approximately
