4000 W

 Introduction
Slim coolers

• Injected gasket on cabinet side as standard.
• Inbuilt condensate evaporator.
• Standard air filter.
• Textured RAL 7035 standard color. Other colors are avialable upon request.
• The connection is performed by means of PLUG-IN terminal boards:
  - TOP - 2 PLUG-IN power supply
    connectors. Alarm control by means
    of a terminal board. Remote ON / OFF. (door micro switch). RS485
    serial interface for remote control (on request).
• Special voltage on request.
• All two-phase and three-phase versions
  can be supplied with different voltages,
  by changing the internal wiring (follow diagrams).

Temperature regulating range (factory set) from /to +30°C / +40°C
Noise level 71 dB (A)
Coolant type R134a
Operating cycle type 100%


                                                                       * Standard version with 50 hz frequency. 60hz version on request

                                                                                                       Optional
                                                                                                       SPECIAL COLOR = R9KLM...
                                                                                                       AISI INOX 304 FRONT COVER = RIKLM...
                                                                                                       AISI INOX 316 FRONT COVER = RI6KLM...
