 Introduction
Indoor roof mounted coolers

• Injected gasket on cabinet side as standard.
• Inbuilt condensate evaporator with a
  particular safety unit blocking the device
  in case of a condensate drain failure.
• Standard air filter.
• Textured RAL 7035 standard color. Other
  colors are available upon request.
• The connection is performed by means of FROR cables:
  - TOP - Overtemperature alarm, door
    contact and condensation level alarm.
    RS485 serial interface for remote control (on demand).
• Versions with non-standard supply
  voltage are available upon request.
• All two-phase and three-phase versions
  can be supplied with different voltages,
  by changing the internal wiring (follow
  diagrams). check the diagrams for available voltages.

Temperature regulating range (factory set) from /to +30°C / +40°C
Noise level 71 dB (A)
Coolant type R134a
Operating cycle type 100%
Weight 72 Kg


                                                                      * Standard version with 50 hz frequency. 60hz version on request

                                                                                                     Optional
                                                                                                     SPECIAL COLOR = R9KLM...
                                                                                                     AISI INOX 304 FRONT COVER = RIKLM...
                                                                                                     AISI INOX 316 FRONT COVER = RI6KLM...
